Point Cloud Example

Plastic wrapped consumer goods

This is a point cloud example captured with a Zivid 2 3D camera. The Zivid 3D color camera covers a wide range of industrial automation applications such as bin-picking, piece picking and machine tending.

  • Product: Zivid 2 3D Camera
  • Working Distance: 30 - 150 cm
  • Target Objects: Plastic wrapped items - handling reflections and interreflections
  • Acquisition: 3D Color HDR merge

Zivid 2 gives you exceptional 3D image quality lightning fast in an ultra-compact form-factor. It helps automation engineers design fast, reliable pick and place robots cells capable of handling a wide variety of challenging objects and scenes. You can view all the point cloud examples using Zivid Studio, our free 3D vision software tool.

View more point clouds

What do you want to capture?

Send us a request, we'll take point cloud images of any object for you.
Contact Us

Drag the slider to compare between the color point cloud from a Zivid 3D camera and the monochrome point cloud from an alternative 3D camera.

Full color point clouds

Don't miss details by using monochrome 3D scanners or TOF sensors. Zivid 3D cameras provide high-definition, high dynamic range point clouds with full RGB colors.

60 µm point precision

Zivid 2 3D detects target objects with single or multi-frame imaging, and have a low occlusion and trueness error (< 0.2%).

Real-time 3D captures

Zivid cameras support fast 3D acquisitions and color point cloud bursts for efficient robotic automation.
