Assembly Automotive #3

Automotive: Shiny Metallic Parts

Here you will find a set of samples of shiny metallic items typically found in automotive manufacturing. This should help you assess the fit of our 3D cameras for your application. If you cannot find the object you are looking for, contact us, and we will capture it for you.

Contact Us




Fastening brackets

Set up:
Working distance: 635 [mm] to the middle of the bin
Capture time: 1070 ms
Camera Model: Zivid 2 M70

Resolution/results:
Spatial Resolution: 0.36 [mm]
Point Precision: 67 [um]
Dimensional Trueness: 0.05%

Full settings file →



Threaded lugs



Set up:
Working distance: 570 [mm] to middle of the bin
Capture time: 637 ms
Camera Model: Zivid One+ Small

Resolution/results:
Spatial Resolution: 0.21 [mm]
Point Precision: 43 [um]
Dimensional Trueness: 0.06%

Full settings file



Cylinders



Set up:
Working distance: 1596 [mm] to middle of the bin
Capture time: 2940 ms
Camera Model: Zivid One+ Large

Resolution/results:
Spatial Resolution: 0.59 [mm]
Point Precision: 431 [um]
Dimensional Trueness: 0.14%

Full settings file

Need to capture something else?

Send us a request, we'll take point cloud images of any object for you.
Contact Us
